LOUVERED FLAGSHIP · THE ASSEMBLY FILM
150BC
THE BIOCLIMATIC SYSTEM, PART BY PART — POSTS, GUTTER, MOTOR, CARRIER, LAMELLAS — ASSEMBLED IN ORDER, THEN SET IN MOTION.
150BC is the louvered line drawn to the millimetre. The film on this page will raise it in documented order — from the ground up, one part at a time — ending with the roof doing the one thing that defines it: turning open sky into shade, and shade into a closed plane that drains.
Until that film is verified, the assembly chapter — sheets S01–S04 and the exploded drawing — remains the deep study.
THE ASSEMBLY FILM — ON THE LOUVERED PAGE
THE FILM — FIVE BEATS, VAULT GEOMETRY
- POSTS STAND150 × 150 MM POSTS TAKE THEIR POSITIONS.
- THE GUTTER CLOSES THE PERIMETER152.5 × 182.8 MM PERIMETER GUTTER — THE TUBULAR MOTOR RIDES INSIDE IT.
- THE CARRIER SPANS150 × 200 MM CARRIER BEAM WITH THE 501 DRIVE RAIL.
- LAMELLAS ARRIVE250 MM BLADES LAND AT 250 MM PITCH — ALUMINUM OR GLASS.
- ROTATIONTHE ROOF TURNS: OPEN SKY → ANGLED SHADE → CLOSED, DRAINING PLANE.
DATA OF RECORD
- POST
- 150 × 150 MM
- CARRIER BEAM
- 150 × 200 MM · 501 DRIVE RAIL
- PERIMETER GUTTER
- 152.5 × 182.8 MM · IN-GUTTER TUBULAR MOTOR
- BLADE
- 250 MM AT 250 MM PITCH
- LAMELLA
- ALUMINUM OR GLASS
- VARIANT
- ROLLING ROOF
THE DIMENSIONS ABOVE ARE THE DOCUMENTED SYSTEM.
